- Overview
The Tyan S5350-D-1UR-RS (also known as the Tiger i7320) is a legacy dual-socket server motherboard designed for 1U rackmount systems. It is built on the Intel E7320 chipset and supports dual Intel Xeon processors from the mid-2000s era.
Specifications
Model Number: S5350-D-1UR-RS
Brand: Tyan
Alt. Part Number(s): S5350-D-1UR-RS
Type: Motherboard
Technical Description
Brand: Tyan
Model: S5350-D-1UR-RS
CPU Socket Type: Dual mPGA604
CPU Type: Dual Intel Xeon
System Bus: 800 MHz
Chipsets: Intel E7320, Intel 6300ESB
Number of DDR Slots: 8 x 184Pin
DDR Standard: DDR 333 (PC 2700)
Max Memory Supported: 16GB
Channel Supported: Dual Channel
ECC Supported: Yes
Video Chipset: ATI RAGE XL
LAN Speed: 10/100/1000Mbps
Second LAN Chipset: Broadcom BCM5721
Second LAN Speed: 10/100/1000Mbps
Max LAN Speed: Dual 10/100/1000Mbps
Ports PS/2: 2
COM Ports: 1
Video Ports: 1
Onboard USB: 2 x USB 2.0
Form Factor: SSI CEB
Width: 12.0”
Length: 10.2"
