Tyan S3850G2NR ServerWorks-HT1000 939-Socket 800Mhz 8Gb ATX Motherboard

Overview

The Tomcat K8SH (S3850) Server Board packs strong server features into a compact ATX form factor. With support for AMD Opteron 100 series processors with Dual Core support, Registered DDR400/333 memory support, dual Gigabit Ethernet ports, SATA RAID, and many built-in firmware and power management features, the Tomcat K8SH provides core server capabilities for today's dense server configurations.

Specifications

Mfr Part Number:  S3850G2NR

Brand:  Tyan

Alt Part No:  S3850G2NR

Type:  Motherboard

Note:  Without Accessories



Technical Description

Brand:  Tyan

Model:  S3850G2NR

Product Line:  Tyan Tomcat K8SH

Chipset:  ServerWorks HT1000

Socket:  Socket 939

Memory:  8GB

Speed:  800 MHz

Total Ports:  24-pin main power connector, 8-pin ATX12V connector

Network:  2 x Gigabit Ethernet

Video Output:  graphics adapter

Graphics:  Processor XGI Volari Z7

Compatible:  Processors Opteron 100 series

Output Voltage:  208 - 230 V AC

Form Factor:  ATX

Width:  12 in

Depth:  9.6 in
