Tyan S2882UG3NR-D-RS AMD-8131 32GB Extended-ATX Motherboard
SPECIAL ORDER ITEM
This product is available for special order and may take longer to ship.
AVAILABILITY & SHIPPING
We source this item directly from the OEM as a special order, which may result in longer lead times. We’ll keep you updated throughout the process.
NEED IT SOONER?
Contact us to explore expedited options or find a comparable in-stock alternative.
SPECIAL ORDER FULFILLMENT
Saitech Inc. sources special orders directly from manufacturers and authorized distributors, including hard-to-find, end-of-life, and build-to-order products. These items may have longer lead times, and our team will keep you informed throughout the process.
- Overview
The TYAN Thunder K8SD Pro (S2882UG3NR-D-RS) is a specific revision of the S2882-D motherboard series, often found in specialized OEM configurations like Xerox Fiery print servers. While it shares the core architecture of the standard S2882UG3NR-D, the "-RS" suffix typically denotes a "Retail Small" or "RoHS Compliant" package revision.
Technical Description
Chipset Model: 8131
Total Processor Supported: 2
Processor Technology: HyperTransport Technology
Processor Socket: Socket PGA-940
Processor Supported: Opteron
Number of Memory Slots: 8
Maximum Memory: 32 GB
Memory Standard: DDR400/PC3200
Memory Standard: DDR266/PC2100
Memory Standard: DDR333/PC2700
Memory Technology: DDR SDRAM
Controller Type: Ultra ATA/133 (ATA-7)
Controller Type: Serial ATA/300
Controller Type: Ultra320 SCSI
Controller Type: Floppy Controller
Onboard Video: On-board Video Chipset
Graphics Controller Manufacturer: ATI
Graphics Controller Model: Rage-XL
Graphics Controller Memory: 8 MB
Gigabit Ethernet: Yes
Number of Total Expansion Slots: 5
Number of PCI Slots: 1
Number of PCI-X Slots: 4
Total Number of USB Ports: 2
Number of USB 1.1 Ports: 2
Serial Port: Yes
VGA: Yes
Number of IDE Interfaces: 2
Number of SATA Interfaces: 4
Number of SCSI Interfaces: 2
Total Number of Onboard USB Ports: 2
Onboard LEDs Header: Yes
Width: 13.0"
Depth: 12.0"
