Tyan Motherboard Tempest I5000vs Intel Blackford-vs Lga771 6ddr2 Sata Raid Video Dual Gblan Ssi Ceb Rohs (S5372G2NR-LH)
Roll over image to zoom in Click on image to zoom
Tyan Motherboard Tempest I5000vs Intel Blackford-vs Lga771 6ddr2 Sata Raid Video Dual Gblan Ssi Ceb Rohs (S5372G2NR-LH)

Tyan Motherboard Tempest I5000vs Intel Blackford-vs Lga771 6ddr2 Sata Raid Video Dual Gblan Ssi Ceb Rohs (S5372G2NR-LH)

Price:
$209.00
TyanSKU: 925484
Model Number: S5372G2NR-LH
Condition: New
In stock:  Yes
No reviews

Description

Tempest i5000VS (S5372-LH) Server Board brims with excellent features and capabilities to maximize performance output. The Tempest i5000VS (S5372-LH) supports two quad-core or dual-core Intel Xeon processors. To comply with various applications and objectives, the S5372-LH also accommodates multiple PCI Express/PCI-X expansion slots and a Remote System Management IPMI 2.0, in addition of Tyan Taro card equipped on the SO-DIMM slot.

S5372G2NR-LH Product Overview

Processor & Chipset

  • Chipset Manufacturer:     Intel
  • Chipset Model:     5000V
  • Total Processor Supported:     2
  • Processor Technology:     Hyper-Threading Technology
  • Processor Socket:     Socket J LGA-771
  • Processor Supported:     Xeon Quad-core
  • Processor Supported:     Xeon Dual-Core
  • Front Side Bus:     1066 MHz
  • Front Side Bus:     1333 MHz
  • 64-bit Processing:     Yes

Memory

  • Number of Memory Slots:     6
  • Maximum Memory:     24 GB
  • Memory Standard:     DDR2-667/PC2-5300
  • Memory Standard:     DDR2-533/PC2-4200
  • Memory Technology:     DDR2 SDRAM

I/O Controller

  • Controller Type:     Serial ATA/300
  • Controller Type:     Ultra ATA/100 (ATA-6)
  • RAID Levels:     1+0
  • RAID Levels:     1
  • RAID Levels:     0

Video

  • Onboard Video:     On-board Video Chipset
  • Graphics Controller Manufacturer:     XGI
  • Graphics Controller Model:     XG20
  • Graphics Controller Memory:     16 MB

Network & Communication

  • Gigabit Ethernet:     Yes

I/O Expansions

  • Number of Total Expansion Slots:     4
  • Number of PCI Slots:     1
  • Number of PCI-X Slots:     1
  • Total Number of PCI Express Slots:     1
  • Number of PCI Express x8 Slots:     1

Interfaces/Ports

  • Total Number of USB Ports:     2
  • Number of USB 2.0 Ports:     2
  • Serial Port:     Yes
  • VGA:     Yes
  • Network (RJ-45):     Yes

Onboard Interfaces

  • Number of IDE Interfaces:     1
  • Number of SATA Interfaces:     4
  • Total Number of Onboard USB Ports:     1
  • Onboard LEDs Header:     Yes

Physical Characteristics

  • Form Factor:     SSI CEB 1.01
  • Width:     12.0"
  • Depth:     10.5"

Miscellaneous

  • Package Contents:
  • Tempest i5000VS (S5372-LH) Server Board
  • 1 x Ultra-DMA-133/100/66/33 IDE cable
  • 2 x Serial ATA power cable
  • 4 x Serial ATA Cable
  • 1 x USB2.0 cable
  • 1 x User's manual
  • 1 x Quick Reference guide
  • 1 x TYAN driver CD
  • 1 x I/O shield
  • 2 x CPU Back Plane
  • Additional Information:

    BIOS:

  • Phoenix BIOS on 8Mbit Flash ROM
  • Support APM 1.2, ACPI 1.0
  • Serial Console Redirect
  • USB boot supported
  • PnP, DMI 2.0, WfM 2.0 Power Management
  • Green Compliant:     Yes
  • Green Compliance Certificate/Authority:     RoHS

Warranty

  • Limited Warranty:     3 Year
