Description
The X7DBU Server Board is designed with the utmost attention to detail to provide you with the highest standards in quality and performance.
- Chipset Manufacturer: Intel
- Chipset Model: 5000P
- Total Processor Supported: 2
- Processor Technology: Enhanced SpeedStep Technology
- Processor Socket: Socket J LGA-771
- Processor Supported: Xeon Quad-core
- Processor Supported: Xeon Dual-Core
- Front Side Bus: 1333 MHz
- Front Side Bus: 1066 MHz
- Front Side Bus: 667 MHz
- 64-bit Processing: Yes
Processor & Chipset
- Number of Memory Slots: 8
- Maximum Memory: 32 GB
- Memory Standard: DDR2-667/PC2-5300
- Memory Standard: DDR2-533/PC2-4200
- Memory Technology: DDR2 SDRAM
Memory
- Controller Type: Floppy Controller
- Controller Type: Serial ATA/300
- Controller Type: Ultra ATA/100 (ATA-6)
- RAID Supported: Yes
- RAID Levels: 0
- RAID Levels: 1
- RAID Levels: 5
- RAID Levels: 1+0
I/O Controller
- Onboard Video: On-board Video Chipset
- Graphics Controller Manufacturer: ATI
- Graphics Controller Model: ES1000
- Graphics Controller Memory: 16 MB
Video
- Gigabit Ethernet: Yes
Network & Communication
- Total Number of USB Ports: 2
- Number of USB 2.0 Ports: 2
- Serial Port: Yes
- VGA: Yes
- Network (RJ-45): Yes
Interfaces/Ports
- Number of IDE Interfaces: 1
- Number of SATA Interfaces: 6
- Total Number of Onboard USB Ports: 2
- Onboard LEDs Header: Yes
Onboard Interfaces
- Width: 12.0"
- Depth: 13.0"
Physical Characteristics
-
Additional Information:
System BIOS:
- BIOS Type: 8Mb Flash EEPROM with Phoenix BIOS
- BIOS Features:
- Plug and Play (PnP)
- SMBIOS 2.3
- DMI 2.3
- PCI 2.2
- ACPI 1.0 / 2.0
- USB Keyboard support
- Left Side: 1 (x8) PCI-Express & 1 UIO slot
- Right Side: 1 64-bit 133MHz PCI-X or 1 (x8) PCI-Express
- Software:
- Optional IPMI (Intelligent Platform Management Interface) 1.5 / 2.0
- Super Doctor III
- Watch Dog
- NMI
- Power Configurations:
- ACPI Power Management
- Main Switch Override Mechanism
- Wake-On-Ring (WOR) header
- Wake-On-LAN (WOL) header
- Power-on mode for AC power recovery
- Internal / External modem remote ring-on
- Green Compliant: Yes
- Green Compliance Certificate/Authority: RoHS
Miscellaneous
Expansion Slots:
Management:
