Supermicro MBD-H12SSL-C-O AMD EPYC 64-Core ATX Server Motherboard
SPECIAL ORDER ITEM
This product is available for special order and may take longer to ship.
AVAILABILITY & SHIPPING
We source this item directly from the OEM as a special order, which may result in longer lead times. We’ll keep you updated throughout the process.
NEED IT SOONER?
Contact us to explore expedited options or find a comparable in-stock alternative.
SPECIAL ORDER FULFILLMENT
Saitech Inc. sources special orders directly from manufacturers and authorized distributors, including hard-to-find, end-of-life, and build-to-order products. These items may have longer lead times, and our team will keep you informed throughout the process.
- Overview
Overview
The Supermicro MBD-H12SSL-C-O is a high-performance single-socket ATX server motherboard optimized for AMD EPYC 7000 series processors. The "-O" suffix indicates the Retail Pack, which includes the motherboard, an I/O shield, and six SATA cables.
Specifications
Model Number: MBD-H12SSL-C-O
Brand: Supermicro
Alt Part Number(s): MBD-H12SSL-C-O
Product Type: Motherboard
Technical Description
Brand: Supermicro
Model Number: MBD-H12SSL-C-O
Series: 7002 / 7003
Processor Type: AMD EPYC
Processor Core: 64-Cores
Processor Socket: Socket SP3 (LGA 4094)
Storage Interfaces: 8 SATA3 + 8 SAS3 + 2 M.2
Network: Dual Gigabit + IPMI LAN
USB: Up to6 × USB 3.0 ports (4 rear + 2 via header)
Graphics: ASPEED AST2500 BMC
Memory Supported: 2TB
Memory Speed: 3200MHz
Memory Type: DDR4
Memory Slots: 8 DIMM slots
Expansion Slots: 5 × PCIe ×16 + 2 × PCIe ×8
Error Detection: ECC
Power Capacity: 270W
Form Factor: ATX
*
