Supermicro MBD-A2SDI-12C-HLN4F-O Intel Atom 12-Core Mini-ITX Server Motherboard
SPECIAL ORDER ITEM
This product is available for special order and may take longer to ship.
AVAILABILITY & SHIPPING
We’re happy to source this item specifically for you! While it may take a bit more time to arrive, we’ll keep you informed every step of the way. Shipping timelines can vary based on the manufacturer's fulfillment schedule.
NEED IT SOONER?
Contact us to explore expedited options or find a comparable in-stock alternative.
SPECIAL ORDER FULFILLMENT
Saitech Inc. partners with top-tier manufacturers and authorized distributors to fulfill special order requests — including hard-to-find, end-of-life, and build-to-order products. Our team ensures every special order is handled with precision, transparency, and dedicated support from start to finish.
- Overview
Overview
The MBD-A2SDI-12C-HLN4F-O is a Mini-ITX embedded server motherboard featuring a 12-core Intel Atom® C3858 SoC, 4 DIMM memory support with ECC, intense storage capacity (12 SATA3 + M.2), quad GbE LAN, and IPMI/BMC remote management — ideal for compact servers, NAS/storage appliances, and industrial network systems requiring low power and robust connectivity.
Specifications
Model Number: MBD-A2SDI-12C-HLN4F-O
Brand: Supermicro
Alt Part Number(s): MBD-A2SDI-12C-HLN4F-O
Product Type: Motherboard
Technical Description
Brand: Supermicro
Model Number: MBD-A2SDI-12C-HLN4F-O
Processor Type: Intel Atom
Processor Model: C3858
Processor Core: 12-Cores/12 Threads
Processor Core: 2.0GHz
Processor Cache: 12MB
Processor Socket: BGA-1310
Storage Interfaces: 12 SATA3 (6Gbps) ports
Network: 4x 1GbE ports via the Intel C3000 SoC
USB: 1 × USB 3.2 Gen1 (Type-A), 4 × USB 2.0
Graphics: ASPEED AST2400 BMC
MemoryCapacity: 64GB
Memory Supported: 256GB
Memory Type: DDR4
Memory Slots: 4 DIMM slots
Expansion Slots: 1 PCIe 3.0 x4 slot
Error Detection: ECC
TDP: 25W
Power Input: 12V DC
Form Factor: Mini-ITX
*
