Sony SNC-DF40N IPELA 1/4-Inch CCD 3-8Mm Network Security Mini Dome Camera

Overview

The Sony SNC-DF40 is a dome-style security camera with a built-in web server and network interface. It has a wide angle zoom lens that ranges from 3 m to 8 mm and its maximum aperture f/1.0 allows the camera to be used in low light environments. It can utilize both JPEG and MPEG4 compression schemes allowing for both smooth video/audio streaming and providing high quality still images over a wide range of network bandwidths.



Specifications

Mfr Part Number:  SNC-DF40N

Brand:  Sony

Model Number:  SNC-DF40N

Type:  Mini Dome Camera



Technical Description

Brand:  Sony

Model:  SNC-DF40N

Max Digital Video Resolution:  640 x 480

Product Line:  Sony IPELA

Image Device:  1/4 Inch CCD

Processor Type:  Pentium III

Processor Speed:  1 Hz

Optical Zoom:  2.7

Lens:  CS Mount on Camera , 3.0 to 8.0 mm f/1.0 Lens

Minimum Illumination:  0.8 Lux at f/1.0 with 50 IRE

Network Interface:  Ethernet 10Base-T/100Base-TX

Network Protocols:  ARP, DHCP, DNS, FTP, HTTP, ICMP, NTP, RTCP, RTP

Power Requirements:  12 Volts DC, 24 Volt AC and PoE Selectable

Power Consumption:  7.5 Watts

Output Voltage:  208 - 230 V AC

Protocols:  Web, SNMP, Telnet

Width:  4.9 in

Depth:  5 in

Height:  5.2 in



Features

30-Day Money Back Guarantee

Full Factory Warranty

Built-in Web Server - View and control using standard web browsers

High resolution - 1/4" type Super HAD CCD

High sensitivity - 0.8 lux (AGC on, F1.0, 50 IRE)

Includes 2.7 x vari-focal lens, with CS mount

Analog video output - 480 TV lines

Bi-directional audio transmission, with external microphone input

Motion detection using motion vector

Equipped with one sensor in and two relay outputs

Back light compensation, ATW and AGC

MPEG-4 and JPEG Compression Formats, selectable

High frame rate: 30fps(QVGA), 15 fps(VGA)

Up to 10 users (MPEG-4 mode); 15 users (JPEG mode)

100Base-TX/10BASE-T
