Puls DIMENSION Q-Series QT20.361 3-Phase 480W AC-to-DC DIN Rail Power Supply
SPECIAL ORDER ITEM
This product is available for special order and may take longer to ship.
AVAILABILITY & SHIPPING
We source this item directly from the OEM as a special order, which may result in longer lead times. We’ll keep you updated throughout the process.
NEED IT SOONER?
Contact us to explore expedited options or find a comparable in-stock alternative.
SPECIAL ORDER FULFILLMENT
Saitech Inc. sources special orders directly from manufacturers and authorized distributors, including hard-to-find, end-of-life, and build-to-order products. These items may have longer lead times, and our team will keep you informed throughout the process.
- Overview
The Puls QT20.361 is a high-efficiency, three-phase AC-to-DC DIN rail power supply designed for industrial automation, control systems and electrical equipment. Part of the DIMENSION Q series, it delivers a regulated 36V DC output at 13.3A, providing up to 480W of continuous power. Its adjustable output voltage, active power factor correction (PFC), high efficiency of up to 94.8% and 150% short-term overload capability make it suitable for demanding industrial applications. The compact design supports DIN rail mounting and includes DC-OK relay monitoring for reliable system operation
Specifications
Model Number: QT20.361
Brand: Puls
Alt Part Number(s): QT20.361
Product Type: Industrial Power Supply
Technical Description
Brand: Puls
Model Number: QT20.361
Series: DIMENSION Q-Series
Input Phase: 3-Phase
Input: 0.79A at 400V / 0.65A at 480V , AC 380–480V
Number of Outputs: 1
Frequency: 50–60Hz
Efficiency: Up to 94.8%
Output: 13.3A at 36V
Output Power: 480W
Peak Output Power: 720W
Mounting Standard: 35mm DIN Rail
Form Factor: DIN Rail Mount
