PowerDSINE PD-6024/AC/M 24-Port POE MIDSPAN HUB

"Image may differ from actual product"

Roll over image to zoom in Click on image to zoom
PowerDSINE PD-6024/AC/M 24-Port POE MIDSPAN HUB

PowerDSINE PD-6024/AC/M 24-Port POE MIDSPAN HUB

Price:
$599.00
PowerDsineSKU: 597064
Model Number: PD-6024/AC/M
Condition: New
In stock:  Yes
Quote
No reviews
SPECIAL ORDER

This item is a Special Order and may take additional shipping time.
Place your order with SAITECH, and we will make every effort to have the item delivered to you as soon as possible.

How We Process Orders
Fastest Shipping: To get your products to you as quickly as possible, most orders placed directly by one of our several leading distributors or by the product's manufacturer. As a result, no one can get your orders to you faster than we can!

Strong Industry Alliances: SAITECH maintains long-standing alliances with the industry's leading distributors and manufacturers. As a result, we are the top source for your computer, office and Server technology needs.

Lowest Possible Prices: Advanced electronic interfaces continually scan our distributors for their best current pricing and availability. While changes in availability between different distributors may result in some price fluctuations, it ensures that you will always receive the lowest possible prices on currently available products!

Realtime Inventory: Live inventory updates are not available for this product.

Description

The PowerDsine 6024 Power over Ethernet Hubs which enable a unified supply of data, voice, video and power through a single access point by sending power over standard Category 5 and above twisted pair cable. Eliminating the need for bulky AC adapters, the Power over Ethernet Hubs enhance the reliability of Ethernet devices, such as IP telephones, wireless LAN access points and Web-cameras. PD-6024 Power over Ethernet midspan offers a unique web-based remote management system (SNMP). This feature enables the various users of the midspan to effectively and easily manage any power hub from a remote location. PowerView allows users to remotely control a large set of parameters on the 24-port power hub unit.

PD-6024/AC/M Product Overview

    Power Description

  • Input Voltage:     110 V AC
  • Input Voltage:     220 V AC
  • Input Voltage Range:     88 V AC to 264 V AC
  • Output Voltage:     -48 V DC
  • Input Current:     1.80 A @ 240 V AC
  • Input Current:     3.50 A @ 110 V AC
  • Frequency:     47 Hz to 63 Hz
  • Output Power:     16.80 W Per Port

    Interfaces/Ports

  • Output Ports:     24 x RJ-45 10/100Base-TX

    Environmental Conditions

  • Temperature:
  • Temperature:
  • Humidity:     90% Non-condensing Operating
  • Humidity:     95% Non-condensing Storage
  • Altitude:     -1000 ft to 10000 ft Operating

    Physical Characteristics

  • Form Factor:     1U Rack-mountable
  • Height:     1.8"
  • Width:     17.0"
  • Depth:     11.9"
  • Weight (Approximate):     8.80 lb

    Miscellaneous

  • Additional Information:
  • Remote Management
  • 1 x management - 9 pin D-Sub (DB-9) Interface
  • Certifications & Standards:
  • IEEE 802.3af Compliant
  • Regulatory Compliance: CE

    • Electromagnetic Emission & Immunity:

  • FCC Part 15 Class B
  • EN55022 Class B
  • EN50082-1

    • Safety Approvals:

  • UL 1950
  • CSA C22.2 No. 950
  • EN 60950
  • TUV EN 60950
  • Green Compliant:     Yes
  • Green Compliance Certificate/Authority:     RoHS

    Warranty

  • Limited Warranty:     Lifetime
