PowerDSINE PD-6024/AC/M 24-Port POE MIDSPAN HUB
SPECIAL ORDER ITEM
This product is available for special order and may take longer to ship.
AVAILABILITY & SHIPPING
We source this item directly from the OEM as a special order, which may result in longer lead times. We’ll keep you updated throughout the process.
NEED IT SOONER?
Contact us to explore expedited options or find a comparable in-stock alternative.
SPECIAL ORDER FULFILLMENT
Saitech Inc. sources special orders directly from manufacturers and authorized distributors, including hard-to-find, end-of-life, and build-to-order products. These items may have longer lead times, and our team will keep you informed throughout the process.
- Overview
The PowerDsine 6024 Power over Ethernet Hubs which enable a unified supply of data, voice, video and power through a single access point by sending power over standard Category 5 and above twisted pair cable. Eliminating the need for bulky AC adapters, the Power over Ethernet Hubs enhance the reliability of Ethernet devices, such as IP telephones, wireless LAN access points and Web-cameras. PD-6024 Power over Ethernet midspan offers a unique web-based remote management system (SNMP). This feature enables the various users of the midspan to effectively and easily manage any power hub from a remote location. PowerView allows users to remotely control a large set of parameters on the 24-port power hub unit.
- Input Voltage: 110 V AC
- Input Voltage: 220 V AC
- Input Voltage Range: 88 V AC to 264 V AC
- Output Voltage: -48 V DC
- Input Current: 1.80 A @ 240 V AC
- Input Current: 3.50 A @ 110 V AC
- Frequency: 47 Hz to 63 Hz
- Output Power: 16.80 W Per Port
Power Description
- Output Ports: 24 x RJ-45 10/100Base-TX
Interfaces/Ports
- Temperature:
- Temperature:
- Humidity: 90% Non-condensing Operating
- Humidity: 95% Non-condensing Storage
- Altitude: -1000 ft to 10000 ft Operating
Environmental Conditions
- Form Factor: 1U Rack-mountable
- Height: 1.8"
- Width: 17.0"
- Depth: 11.9"
- Weight (Approximate): 8.80 lb
Physical Characteristics
- Additional Information:
- Remote Management
- 1 x management - 9 pin D-Sub (DB-9) Interface
- Certifications & Standards:
- IEEE 802.3af Compliant
- Regulatory Compliance: CE
- FCC Part 15 Class B
- EN55022 Class B
- EN50082-1
- UL 1950
- CSA C22.2 No. 950
- EN 60950
- TUV EN 60950
- Green Compliant: Yes
- Green Compliance Certificate/Authority: RoHS
Miscellaneous
Electromagnetic Emission & Immunity:
Safety Approvals:
- Limited Warranty: Lifetime
Warranty
