Description
Overview
PHISON XX106H007T68P028T1900 Pascari X100P 7.68TB U.2 Dual Port PCIe Gen4x4 Non-Opal SSD
Specifications
Model Number: XX106H007T68P028T1900
Brand: PHISON
Alt Part Number(s): XX106H007T68P028T1900
Product Type: Solid State Drive
Technical Description
Brand: PHISON
Model: XX106H007T68P028T1900
Capacities: 7.68TB
Form Factor: U.2
Security: Non-Opal
PCIe Interface
PCIe Gen4x4
Dual Port x2 lanes
PCIe AER (Advanced Error Reporting)
Performance
Maximum Sequential Read / Write: 7000MB/s / 6800MB/s
Maximum Random Read / Write: 1600KIOPS / 180KIOPS
Sustained Random Read / Write Latency(µs): 100/15(QD=1, Workers=1); 110/300(QD=32, Workers=1); 450/3800(QD=64, Workers=8)
IOPS Consistency: 95%
QoS (Quality of Service, 99%) Read / Write: 100/12(QD=1, Workers=1); 130/200(QD=32 Workers=1); 600/3200(QD=64, Workers=8)
Power Consumption
Random Read/Write (Typ): 15.7/17.4 W
Sequential Read/Write (Typ): 11.6/19.1 W
Inrush Current: 1.5A
Idle Power (Typ): 5.75 W
DWPD: 1DWPD
TBW: 14.02TB
LBAF: 512 / 512+8 / 4K / 4K+8 / 4K+64 Bytes
MTBF: 2,500,000 hours
UBER (Uncorrectable Bit Error Rate): < 1 sector per 10^18 bits read
Advanced Flash Management
ECC
Static and Dynamic Wear Leveling
Bad Block Management
Deallocate (TRIM) Command
SMART
Over-Provision
Firmware Upgrade
Temperature Range
Operation: 0 °C - 70 °C with specified airflow
Storage: -40 °C - 85 °C
RoHS: Compliant
Enterprise Features Support List
Namespace
Dual Port
Reservation
Metadata Protection
Thermal throttling
Power Loss Protection
Hardware AES-XTS 256-bit Encryption
Support SMBus
Support NVMe-MI (Management Interface)
Data Retention: 3 months
Compliance
PCIe Express Base 4.0
NVMe 1.4
NVMe Management Interface Rev 1.1
