Intel Motherboard D915GAVX LGA775 800FSB 4DDR Aud Vdo SATA ATX ROHS

IntelSKU: 10646
Model Number: D915GAV
Condition: Refurbished
In stock:  Yes
No reviews

Price:
Sale price$69.00

Description

The Intel Desktop Boards D915GAV supports the latest Intel Pentium 4 processors featuring Hyper-Threading Technology and is designed to optimize a broad range of usage models in the office and at home. This desktop board features Intel High Definition Audio, and PCI Express expansion slots. In addition, this desktop board delivers exceptional platform flexibility with both PCI Express x16 graphics and Intel Graphics Media Accelerator 900, as well as dual-channel DDR 400/333 memory.

D915GAV Product Overview

Processor & Chipset

  • Chipset Manufacturer:     Intel
  • Chipset Model:     915G
  • Total Processor Supported:     1
  • Processor Technology:     Hyper-Threading Technology
  • Processor Socket:     Socket T LGA-775
  • Processor Supported:     Pentium 4
  • Processor Supported:     Pentium 4 (Extreme Edition)
  • Processor Supported:     Celeron D
  • Front Side Bus:     533 MHz
  • Front Side Bus:     800 MHz

Memory

  • Number of Memory Slots:     4
  • Maximum Memory:     4 GB
  • Memory Standard:     DDR400/PC3200
  • Memory Standard:     DDR333/PC2700
  • Memory Technology:     DDR SDRAM

I/O Controller

  • Controller Type:     Ultra ATA/100 (ATA-6)
  • Controller Type:     Floppy Controller
  • Controller Type:     Serial ATA/150

Video

  • Onboard Video:     On-board Video Chipset
  • Graphics Controller Manufacturer:     Intel
  • Graphics Controller Model:     GMA 900

Audio

  • Sound Controller Manufacturer:     Realtek
  • Sound Controller Model:     ALC860

I/O Expansions

  • Number of Total Expansion Slots:     7
  • Number of PCI Slots:     4
  • Total Number of PCI Express Slots:     3
  • Number of PCI Express x1 Slots:     2
  • Number of PCI Express x16 Slots:     1

Interfaces/Ports

  • Total Number of USB Ports:     4
  • Number of USB 2.0 Ports:     4
  • Parallel Port:     Yes
  • Serial Port:     Yes
  • Audio Line In:     Yes
  • Audio Line Out:     Yes
  • Microphone Port:     Yes
  • VGA:     Yes

Onboard Interfaces

  • Number of IDE Interfaces:     1
  • Number of SATA Interfaces:     4
  • Total Number of Onboard USB Ports:     2
  • Onboard LEDs Header:     Yes
  • Onboard Audio Header:     Yes

Power Description

  • Power Supply Supported:     ATX12V

Physical Characteristics

  • Width:     12.0"
  • Depth:     9.6"

Miscellaneous

  • Package Contents:
  • D915GAV Desktop Board
  • ATX 2.01 compliant I/O shield
  • Floppy, SATA, and ATA 100/66 cables
  • Board and back-panel I/O layout stickers
  • Quick Reference Guide
  • Intel Express Installer CD, including:
    • Intel Desktop Utilities*
    • Norton Internet Security
    • NTI CD-Maker
    • Musicmatch Jukebox
    • Sonic Focus
    • InterVideo Home Theater Silver
    • InterVideo WinDVD Creator Silver
    • Farstone RestoreIT! Lite
    • Software Drivers
    • Desktop Board Product Guide
    * Intel Desktop Utilities includes: Hardware monitoring, Diskeeper Lite defragmentation, NTI Backup Now, StressTest, Symantec Security Check.
  • Additional Information:

    System Memory:

  • Minimum total system memory: 128 MB
  • Serial Presence Detect
  • Double-sided DIMMS with x16 organization are not supported
  • Intel 915G Chipset:

  • Intel 82915G Graphics Memory Controller Hub (GMCH) with Direct Media Interface (DMI)interconnect
  • Intel 82801FB I/O Controller Hub (ICH6) with DMI interconnect
  • Audio Subsystem:

  • Advanced jack sense (front and rear panel) that enables the audio codec to recognize the device that is connected to an audio port. All jacks are capable of retasking according to user's definition, or can be automatically switched depending on the recognized device type
  • Stereo input and output for all jacks
  • A signal-to-noise (S/N) ratio of 90 dB
  • Intel Precision Cooling Technology:

  • Advanced management ASIC supports temperature-based fan control
  • Automatically adjusts the processor fan speed based on the processor temperature and adjusts the chassis fan speeds depending on the system temperature
  • System fan noise may be reduced by operating controlled chassis and processor fans at the minimum necessary speeds
  • Certifications & Standards:

    Safety Regulations:

  • UL 60950-1:2003/ CSA C22.2 No. 60950-1-03 (USA and Canada)
  • EN 60950-1:2002 (European Union)
  • IEC 60950-1:2001 (International)
  • EMC Regulations:

  • FCC (Class B) (USA)
  • ICES-003 (Class B) (Canada)
  • EN55022: 1998 (Class B) (European Union)
  • EN55024: 1998 (European Union)
  • AS/NZS 3548 (Class B) (Australia and New Zealand)
  • CISPR 22, 3rd Edition (Class B) (International)
  • CISPR 24: 1997 (International)
  • VCCI (Class B) (Japan)
