"Image may differ from actual product"
Roll over image to zoom in Click on image to zoom
Intel BOXDG965WHMKR D41692 G965 Express LGA-775 ATX Motherboard
SPECIAL ORDER ITEM
This product is available for special order and may take longer to ship.
AVAILABILITY & SHIPPING
We source this item directly from the OEM as a special order, which may result in longer lead times. We’ll keep you updated throughout the process.
NEED IT SOONER?
Contact us to explore expedited options or find a comparable in-stock alternative.
SPECIAL ORDER FULFILLMENT
Saitech Inc. sources special orders directly from manufacturers and authorized distributors, including hard-to-find, end-of-life, and build-to-order products. These items may have longer lead times, and our team will keep you informed throughout the process.
- Overview
Overview
The Intel BOXDG965WHMKR is an excellent motherboard, suitable for any ATX desktop computer chassis, and a top choice for the Socket T LGA 775) environment, ready for the Core 2 Duo and Conroe processors. It delivers superior stability and a range of new features for users to enjoy a great digital entertainment experience. Based on an Intel G965 Express Chipset, it supports 1066/800MHz system FSB for faster transfers and screaming operations. The onboard SigmaTel STAC9271D chipset and Intel GMA X3000 chipset deliver high-quality audio and video performance, supported by the onboard Intel 82566DC LAN chipset with maximum LAN speed of up to 1000Mbps! This board is ready to amaze you with Dolby Home Theater certification and Intel's ViiV technology for a spectacular digital entertainment experience. It includes ten USB 2.0 ports, two IEEE-1394, six Serial ATA, and one Parallel ATA interface. It has three PCI Express x1 slots, one PCI Express x16 slot, and three convential PCI slots, to attach add-on cards and additional function. The Intel G965 Express Chipset supports the new Microsoft Windows Vista sporting the revolutionary Windows Aero GUI interface. For big performance in a small package, look no further!
Specifications
Model Number: BOXDG965WHMKR
Brand: Intel
Alt Part Number(s): D41692
Product Type: Motherboard
Technical Description
Brand: Intel
Model: BOXDG965WHMKR / D41692
CPU Socket Type: LGA 775
CPU Type: Core 2 Duo / Pentium D / Celeron D
FSB: 1066/800 MHz
Chipset: Intel G965 Express, Intel ICH8R
Number of Memory Slots: 4×240pin
Memory Standard: DDR2 800
Maximum Memory Supported: 8GB
Channel Supported: Dual Channel
PCI Express x16: 1 x PCI Express x16
PCI Express x1: 3 x PCI Express x1
PCI Slots: 3 x PCI Slots
PATA: 1 x ATA100 2 Dev. Max
SATA 3Gb/s: 6 x SATA 3Gb/s
SATA RAID: 0/1/0+1/5 Matrix RAID
Onboard Video Chipset: Intel GMA X3000
Audio Chipset: SigmaTel STAC9271D
Audio Channels: 8 Channels
LAN Chipset: Intel 82566DC
Max LAN Speed: 10/100/1000Mbps
PS/2 Ports: 2
LPT Ports: 1
Video Ports: D-Sub
USB 1.1/2.0: 6 x USB 2.0
IEEE 1394: 1 x IEEE 1394a
S/PDIF Out: 1 x Optical
Audio Ports: 5 Ports
Onboard USB: 4 x USB 2.0
Onboard 1394: 1 x 1394a
Form Factor: ATX
Dimensions (W x L): 11.6" x 9.6"
Windows Vista: Certified for Windows Vista
Power Pin: 24 Pin
Features
Notice: Only DDR2-800 memory supporting JEDEC approved 1.8V operation with timings of 5-5-5 or 6-6-6 is supported on Intel Desktop Boards based on Intel 965 Express Chipsets.
*
