Intel BLKDG965WHMKR Chipset-G965 Express Socket-LGA775 8Gb DDR2-800MHz 24-Pin ATX Motherboard

Specifications

Model Number:  BLKDG965WHMKR

Brand:  Intel

Alt. Part Number(s):  BLKDG965WHMKR

Product Type:  Motherboard

Note:  Refurbished Motherboard with Backplate Only.



Technical Description

Brand:  Intel

Model:  BLKDG965WHMKR

CPU Socket Type:  LGA 775

CPU Type:  Core 2 Duo / Pentium D / Celeron D

FSB:  1066/800MHz

Supported CPU Technologies:  Hyper-Threading Technology

Chipset:  Intel G965 Express, Intel ICH8R

Number of Memory Slots:  4×240pin

Memory Standard:  DDR2 800

Maximum Memory Supported:  8GB

Channel Supported:  Dual Channel

PCI Express x16:  1

PCI Express x1:  3

PCI Slots:  3

PATA:  1 x ATA100 2 Dev. Max

SATA 3Gb/s:  6

SATA RAID:  0/1/0+1/5 Matrix RAID

Onboard Video Chipset:  Intel GMA X3000

Audio Chipset:  SigmaTel STAC9271D

Audio Channels:  8 Channels

LAN Chipset:  Intel 82566DC

Max LAN Speed:  10/100/1000Mbps

PS/2 Ports:  2

LPT Ports:  1

Video Ports:  D-Sub

USB 1.1/2.0:  6 x USB 2.0

IEEE 1394:  1 x IEEE 1394a

Power Pin:  24 Pin

S/PDIF Out:  1 x Optical

Audio Ports:  5 Ports

Onboard USB:  4 x USB 2.0

Onboard 1394:  1 x 1394a

Windows Vista:  Certified for Windows Vista

Form Factor:  ATX

Dimensions (W x L):  11.6" x 9.6"

Features

Notice: Only DDR2-800 memory supporting JEDEC approved 1.8V operation with timings of 5-5-5 or 6-6-6 is supported on Intel Desktop Boards based on Intel 965 Express Chipsets.
