- Overview
Overview
HPE P87776-005 ProLiant Compute DL320 Gen12 is a 1U server powered by an Intel Xeon 6515P 16 core processor running at 2.3 GHz. It includes 64 GB DDR5 memory at 6400 MHz, supports up to 4 TB RAM, offers 8 drive bays, and features dual 1000 W power supplies with 10Gb Ethernet connectivity.
Specifications
Model Number: P87776-005
Brand: HPE
Alt Part Number(s): P87776-005
Product Type: Server
Technical Description
Brand: HPE
Model: P87776-005
Cabinet Form Factor: 1U, GPU Server
Processor / Type: Xeon
Processor / Manufacturer: Intel
Processor / Number: 6515P
Processor / Clock Speed: 2.3 GHz
Max Turbo Frequency: 3.8 GHz
Multi-Core Technology: 16-Core
Processor / Installed Qty: 1
Cache Memory Installed Size: 72 MB
RAM / Technology: DDR5
RAM / Total Installed Size: 64 GB
RAM / Memory Speed: 6400 MHz
RAM Form Factor: RDIMM
RAM / Installed Qty: 1
RAM / Total Slots Qty: 16
RAM / Max Supported Size: 4 TB
Hard Drive / Size: 2.5"
Hard Drive / Bays Qty: 8
Networking Type: Ethernet
Data Link Protocol: Gigabit Ethernet
Network Controller: Broadcom BCM57416 Ethernet 10Gb 2-port BASE-T Adapter
Storage Controller Type: MR408i-o
Power / Device Type: Power Supply
Power / Installed Qty: 2
Power / Provided (W): 1000 Watt
80 PLUS Certification: 80 PLUS Titanium
Interfaces & Connections: iLO Service; USB 3.2 Gen1; VGA; 2 USB 3.2; Dedicated iLO network
Front I/O Ports: iLO Service; USB 3.2 Gen1
Rear I/O Ports: VGA; 2 USB 3.2; Dedicated iLO network
Expansion Slots Total (Free): Up to 6 PCIe Gen5; 2 OCP 3.0 with Rich IO Processor
Width: 17.11 Inch
Depth: 23.92 Inch
Height: 1.69 Inch
Service & Support Type: Three years of parts; three years of labor; three years of on-site support coverage
Min Operating Temperature: 10 Celsius
Max Operating Temperature: 35 Celsius
Humidity Range Operating: 8% to 90%
