Gigabyte A620M GAMING X AX AMD Socket AM5 4 x DDR5 DIMM Micro ATX Gaming Desktop Motherboard
SPECIAL ORDER ITEM
This product is available for special order and may take longer to ship.
AVAILABILITY & SHIPPING
We source this item directly from the OEM as a special order, which may result in longer lead times. We’ll keep you updated throughout the process.
NEED IT SOONER?
Contact us to explore expedited options or find a comparable in-stock alternative.
SPECIAL ORDER FULFILLMENT
Saitech Inc. sources special orders directly from manufacturers and authorized distributors, including hard-to-find, end-of-life, and build-to-order products. These items may have longer lead times, and our team will keep you informed throughout the process.
- Overview
Overview
Gigabyte A620M GAMING X AX Gaming Desktop features an AMD AM5 socket supporting Ryzen 7000, 8000, and 9000 series CPUs with DDR5 memory up to 256 GB. It includes PCIe 4.0 expansion, M.2 and SATA storage, Wi-Fi 6E, Bluetooth 5.2, high-definition audio, and HDMI/DisplayPort outputs in a Micro ATX form factor.
Specifications
Model Number:A620M GAMING X AX
Brand: Gigabyte
Alt Part Number(s):A620M GAMING X AX
Product Type: Gaming Desktop Motherboard
Technical Description
Brand: Gigabyte
Model:A620M GAMING X AX
CPU Socket: AMD AM5
Supported CPUs: AMD Ryzen™ 7000 Series; AMD Ryzen™ 8000 Series; AMD Ryzen™ 9000 Series
Chipset: AMD A620
Memory Type: DDR5; up to 8000(OC) MT/s
Memory Slots: 4 DIMM; up to 256 GB
Memory Features: Dual channel; AMD EXPO™ support; XMP support
Integrated Graphics: DisplayPort 1.4 up to 3840 × 2160 @144 Hz; HDMI 2.1 up to 4096 × 2160 @60 Hz
Expansion Slot: 1 × PCIe x16 slot for dedicated GPU; PCIe 4.0 support depending on CPU
M.2 SSD Slot: 1 slot; PCIe 4.0 x4/x2
SATA Ports: 4 × SATA 6 Gb/s
RAID Support: RAID 0; RAID 1; RAID 10 for NVMe and SATA
LAN: Realtek GbE; 1 Gbps
Wi-Fi: Wi-Fi 6E; 2.4 GHz; 5 GHz; 6 GHz
Bluetooth: 5.2
Audio Codec: Realtek High Definition Audio
Audio Channels: 2-channel; 4-channel; 5.1-channel; 7.1-channel configurable
USB Ports: USB 3.2 Gen 2 Type-A; USB 3.2 Gen 2 Type-C
Display Outputs: HDMI; DisplayPort
Other I/O: RJ-45 LAN; audio jacks; PS/2 port
Cooling & Monitoring: Fan speed control; voltage monitoring; temperature monitoring; water cooling support
BIOS: AMI UEFI BIOS; Q-Flash; Q-Flash Plus
Software Support: Gigabyte Control Center
Bundled Software: Norton Internet Security OEM
OS Support: Windows 10 64-bit; Windows 11 64-bit
Form Factor: Micro ATX; 24.4 cm × 24.4 cm
*
