Intel BOXNUC5I7RYH Core i7-5557U DDR3L-1600Mhz SODIMM NUC Kit .
SPECIAL ORDER ITEM
This product is available for special order and may take longer to ship.
AVAILABILITY & SHIPPING
We’re happy to source this item specifically for you! While it may take a bit more time to arrive, we’ll keep you informed every step of the way. Shipping timelines can vary based on the manufacturer's fulfillment schedule.
NEED IT SOONER?
Contact us to explore expedited options or find a comparable in-stock alternative.
SPECIAL ORDER FULFILLMENT
Saitech Inc. partners with top-tier manufacturers and authorized distributors to fulfill special order requests — including hard-to-find, end-of-life, and build-to-order products. Our team ensures every special order is handled with precision, transparency, and dedicated support from start to finish.
- Overview
Overview
Equipped with a 5th generation Intel® Core™ i7-5557U processor, NUC5i7RYH is the highest performing Intel® NUC ever. Iris™ graphics 6100 delivers amazing multimedia experiences and makes NUC5i7RYH perfect for immersive gaming. A replaceable lid provides plenty of options to extend system capabilities or add personal style. Intel® Turbo Boost Technology 2.0 delivers performance that adapts to your needs. Add a 2.5-inch HDD or an M.2 SSD for more storage. Complete with Wi-Fi 802.11ac wireless, Bluetooth, and 7.1 surround sound, NUC5i7RYH is ideal for home theater PCs, media server PCs, and home hubs.
Specifications
Mfr Part Number: BOXNUC5I7RYH
Brand: Intel
Model Number: BOXNUC5I7RYH
Type: NUC Kit
Technical Description
Brand: Intel
Model: BOXNUC5I7RYH
Series: NUC (Next Unit of Computing)
Color: Black
CPU Type: Intel 5th Generation Core i7-5557U (3.1GHz up to 3.4GHz Turbo, Dual Core, 4MB Cache, 28W TDP)
Memory installed: No Memory
Memory slot: 2 x 204Pin SO-DIMM
Memory Type Supported: DDR3L 1600/1333
Max Memory Supported: 16GB
Dual Channel Memory Supported: Yes
Hard Drive Installed: No Hard Drive
Serial ATA: 1 x SATA 6.0Gb/s
Onboard Video: Intel Iris Graphics 6100
Audio Channel: 7.1 Channel
Max LAN Speed: 10/100/1000Mbps
Wireless LAN: Intel Wireless-AC 7265 M.2 soldered-down, wireless antennas (IEEE 802.11ac, Bluetooth 4, Intel Wireless Display)
Bluetooth: Yes
2.5" Internal Bays: Internal SATA3 support for 2.5" HDD/SSD (up to 9.50mm thickness)
Front USB: 2 x USB 3.0 ports on the front panel (1 x charging capable)
Other Front Ports: Consumer Infrared sensor on the front panel
Rear USB: 2 x USB 3.0, 2 x Internal USB 2.0 via header
Power Supply: 19V, 65W wall-mount AC-DC power adapter, Multi-country plugs (IEC types A/C/G/I)
Dimensions: 1.92" x 4.37" x 4.53"
Material: Aluminum and Plastic
Additional Features
Support for user-replaceable 3rdparty lids
NFC and AUX_PWR headers
OS: Windows 7 & 8.1 logo'd; Linux compatibility
VESA mount bracket and mounting hole support
Low-acoustics active cooling design
Kensington lock support
Integration Guide
12-19V DC Power Input
Power sensing circuit for protection against over-power shutdowns
*
