Description
Overview
The Axis Communications AXIS P3304 Network Camera uses a 1 megapixel CMOS sensor to capture the surveillance area in HDTV quality. Progressive scan and wide dynamic range technology further aid the camera in maintaining image clarity in various scene and lighting environments. The AXIS P3304 camera supports multiple video streaming using the H.264 or MJPEG compression schemes. Each video stream can be individually adjusted for frame rates and bandwidth to suit a particular network structure. While not vandal resistant, this camera incorporates a tamper-resistant design, which together with its compact profile makes it suitable for installation in retail stores, hotels, and similar sensitive commercial establishments. A unique feature of this camera is its pixel counter function, which calculates the number of pixels contained in a given part of the image, for example, a person's face. This is an important feature for satisfying certain jurisdictions that require proof of resolution before an image can be submitted as evidence. This camera also has the ability to detect and activate an alarm if it detects the lens being blocked or spray painted. Alarm I/O ports allow the use of external alarm and relay devices. The ability to power the camera via the Ethernet cable (PoE) offers greater flexibility in camera placement while cutting down on installation costs.
Specifications
Model Number: P3304
Brand: Axis
Alt Part Number(s): 0352-001
Type: Network Security Camera
Technical Description
Brand: Axis
Model: P3304 / 0352-001-02
Image Sensor: 1/4" color progressive scan RGB CMOS
Resolution: 1280 x 800
Lens: 2.8-10mm, F1.7, angle of view: 80-22° (horizontal)
Iris Operation: DC iris
Pan & Tilt: Physical - Pan 360°, tilt 170°, rotation 340°
Digital PTZ: Digital PTZ, preset positions, guard tour
Minimum Illumination: 0.9 lux F1.7
IR Illumination: None
Audio: Built-in microphone, external microphone input or line input, line level output (2-way audio)
Controls: Compression, color, brightness, sharpness, contrast, white balance, exposure control, exposure zones, backlight compensation, wide dynamic range - dynamic contrast, fine tuning of behavior at low light, rotation, mirroring of images
Alarm I/O: 1 alarm input, 1 alarm output
Compression Format: H.264 (MPEG-4 Part 10/AVC), Motion JPEG
Video Streaming: Multiple, individually configurable streams in H.264 and Motion JPEG, Controllable frame rate and bandwidth, VBR/CBR H.264
Supported Protocols: IPv4/v6, HTTP, HTTPS, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Picture Size: 1280 x 800 to 160 x 90
Frame Rate: 30 FPS in all resolutions
Built-In SD Card Slot: None
Alarm events: File upload via FTP, HTTP and email / Notification via email, HTTP and TCP / External output activation
Network Interface: RJ-45 10BASE-T/100BASE-TX
Construction: Tamper-resistant plastic casing, Polycarbonate transparent cover, Metal inner camera module with encapsulated electronics
Power Requirements: 4.9 - 5.1 V DC max. 4.7 W, Power over Ethernet IEEE 802.3af Class 2 (max. 4.7 W)
Operating Temperature: 32 To 122 Degree (0 - 50 Degree C)
Dimensions (WxH): 5.7 x 3.7" (144 x 94mm)
* Product descriptions and part numbers are subject to change, and may not reflect manufacturer product changes. Please check the manufacturer's website and use the item's manufacturer part number to find the most up to date product description.
