Description
Overview
AXIS 214 PTZ Network Camera is a high performance camera for professional surveillance and remote monitoring. It combines a high quality color camera with the flexibility of remote pan/tilt/zoom operations through operator control. Incorporating an 18x optical motorized lens with auto focus, the AXIS 214 PTZ allows the user to zoom in on a small or distant object with exceptional clarity. The movability of the camera enables it to cover a wide field of view. With automatic day/night functionality and the highly light sensitive CCD, this camera provides perfect color images in low-light conditions as well as sharp black and white pictures in extremely poor lighting conditions. The built-in audio support enables remote users to not only view, but also listen in on an area and communicate orders or requests to visitors or intruders, thereby increasing the monitoring options.
Specifications
Model Number: 0246-004
Brand: Axis
Alt Part Number(s): Axis 214
Product Type: Network Security Camera
Technical Description
Brand: Axis
Model: 0246-004 / Axis 214
Camera Signal: Network IP
Connection Type: Wired, Wireless
Infrared Distance: Non Infrared
Lens Type: Motorized Zoom
Lens Size: 18X
Mount Type: Ceiling, Wall
Compression Method: MPEG-4, M-JPEG
Durability: Indoor
Voltage: 12vDC
Dimensions (W x H): 5.9 x 7.1 x 6.2" (152 x 179 x 157mm)
Electronic Shutter: 1/10000 s to 1 s
Image Device: 1/4” ExView HAD CCD
Minimum Scene Illumination: Color mode: 0.3 lux. Black/white mode: 0.005 lux
Operating Humidity: 20 – 80% RH
Operating Temperature: 0 – 45 ºC (32 – 113 ºF)
Power Consumption: 14 W
Protocols: IPv4/v6, HTTP, HTTPS, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour,UPnP, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, RTSP, RTP, TCP,UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Signal System: NTSC, PAL
Video Output: RJ-45 10BASE-T/100BASE-TX
Zoom Ratio: 18x
Processor: ETRAX 100LX, ARTPEC-2, 32 MB RAM, 8 MB Flash
Angle of View: 2.7° – 48°
Product Type: Network Security Camera
Height: 7.0"
Width: 6.0"
Depth: 6.2"
Features
18x optical zoom and auto focus
Max resolution 4CIF
1/4" Sony ExView HAD interlaced CCD
Minumum Lux: 0.3 Color, .005 B/W
Video compression: Motion JPEG, MPEG-4
Up to 30 Frames Per second
Pan/Tilt/Zoom: 20 Presets
Pan range:340 degree, Tilt range:120 degree
Multi-level password, IP address filtering, HTTPS encryption
1 Alarm Input, 1 Output
2-Way Audio Support (external mic and speakers required)
Motion detection
*Product descriptions, images, and part numbers are subject to change and may not accurately reflect manufacturer product alterations. For the latest and most precise information, kindly refer to the manufacturer's website and use the item's manufacturer part number.
