Axis P5624-E MK II 23x Optical HD Outdoor Day-Night Vandal-Resistant PTZ Dome Camera

Overview

The P5624-E Mk II 720p Outdoor Network PTZ Dome Camera from Axis Communications has a 1/2.8" progressive scan CMOS sensor to capture 1280 x 720 resolution at up 60 fps, and features a 4.3 to 98.9mm varifocal lens for a 57.9 to 2.9° horizontal field of view. The camera compresses footage using H.264 and MJPEG formatting to optimize bandwidth and storage while ensuring high-quality recording and playback. A microSD slot supports local storage via a microSD card (available separately). The camera is housed in an IP66-, NEMA 4X-, and IK10-rated enclosure for protection against water, dust, corrosion, ice, and impact, making it suitable for outdoor use in harsh weather conditions and high-risk areas.



Specifications

Mfr Part Number:  P5624-E Mk II

Brand:  Axis

Alt Part Number:   0932-001

Type:  PTZ Dome Camera



Technical Description

Brand:  Axis

Model:  P5624-E Mk II

Image sensor:  Progressive scan CMOS 1/2.8”

Resolutions:  1280x720 (HDTV 720)

Min Focal Length:  4.3 millimetre

Max Focal Length:  98.9 millimetre

Optical Zoom:  23x Zoom

Horizontal field of view:  57.9°–2.9°

Vertical field of view:  33.9°–1.6

Memory:  512 MB RAM, 256 MB Flash

Network Interface:  Ethernet 10Base-T/100Base-TX

Network Protocols:  NTP, RTSP, IPv6, DDNS, SSH, RTCP, IGMP, SNMP 2c, SSL, FTP, HTTPS, IPv4, TLS

Power Consumption Operational:  8 watt

Output Voltage:  208 - 230 V AC

Protocols:  Web, SNMP, Telnet



Features

Captures 1280 x 720 resolution video at up 60 fps

4.3 to 98.9mm varifocal lens has a 57.9 to 2.9° horizontal field of view

360° endless panning, 180° tilting, 23x optical zoom, and 12x digital zoom

Wide Dynamic Range up to 120 dB for accurate images in varying lighting conditions

RJ45 Ethernet connection with PoE for data and power transmission over a single Ethernet cable

microSD slot for edge storage

IP66-, NEMA 4X-, and IK10-rated for outdoor use
