Axis 225FD / 0243-004 2.8-5.8Mm Lens Vandal Resistant Outdoor POE Dome IP Security Camera
SPECIAL ORDER ITEM
This product is available for special order and may take longer to ship.
AVAILABILITY & SHIPPING
We’re happy to source this item specifically for you! While it may take a bit more time to arrive, we’ll keep you informed every step of the way. Shipping timelines can vary based on the manufacturer's fulfillment schedule.
NEED IT SOONER?
Contact us to explore expedited options or find a comparable in-stock alternative.
SPECIAL ORDER FULFILLMENT
Saitech Inc. partners with top-tier manufacturers and authorized distributors to fulfill special order requests — including hard-to-find, end-of-life, and build-to-order products. Our team ensures every special order is handled with precision, transparency, and dedicated support from start to finish.
- Overview
Overview
The Axis AXIS 225FD is a high performance network camera capable of providing effective security monitoring both day and night and in potentially unstable outdoor environments. This makes it an excellent choice for 24-hour outdoor security surveillance for schools, prisons, construction sites, shipping facilities, transportation hubs and numerous other applications where the camera might be at risk from intentional or accidental damage.
Specifications
Model Number: 225FD
Brand: Axis
Alt Part Number(s): 0243-004
Product Type: Network Security Camera
Technical Description
Brand: Axis
Model: 225FD
Image Sensor: 1/4" Sony Wfine progressive scan RGB CCD
Focal Length: 2.8-5.8mm varifocal, F1.4
Horizontal Angle of View: 75-36°
Focus Range: 0.3m to infinity
Iris Operation: Auto DC
Minimum Illumination: Color - 1 lux (F1.4), B/W - 0.2 (F1.4)
IR Illumination: No
Built-In Microphone: No
Audio Input: No
Audio Output: No
Controls: 90°, 180°, 270° Rotation, Electronic Shutter, Color Level, Brightness, Sharpness, Contrast, White Balance, Exposure Area, Back Light Compensation, Low Light Fine Tuning
Alarm I/O: 2 alarm inputs, 1 alarm output
Control Connector: RS-485/422
Compression Format: Simultaneous MJPEG and MPEG-4 (11 compression levels for MJPEG, 23 compression levels for MPEG-4)
Supported Protocols: IP, HTTP, HTTPS, SSL/TLS, TCP, ICMP, SNMPv1/v2c/v3 (MIB-II), RTSP, RTP, UDP, IGMP, RTCP, SMTP, FTP, DHCP, UPnP, ARP, DNS, DynDNS, SOCKS, NTP etc. More
Picture Size: 16 resolutions from 640x480 to 160x120 via API
Frame Rate: Motion JPEG: Up to 30 frames per sec in all resolutions, MPEG-4: Up to 30 frames per sec in 480 x 360 or lower
Built-In SD Card Slot: No
Web Browser Access: Camera live view, sequence tour capability for up to 20 Axis video sources, customizable HTML pages
Simultaneous Client Access: 20 simultaneous users of which 10 with audio, Unlimited users using multicast (MPEG-4)
Multiple Camera Views: Yes
Motion Detection: Yes
Network Interface: RJ-45 (10BaseT/100BaseTX)
Power Requirements: Camera Heater & Fan, 12 VDC or 24 VAC
Camera & Heater: 9-24 VDC, 10-24 VAC or PoE
Power Consumption: 20W (with heater & fan)
Operating Temperature: -4 ~ 122°F (-20 ~ +50°C)
Diameter and Height: 6.1 x 4.5"
System Requirements
Windows XP, NT 4.0, ME or 98
Pentium III 500MHz or higher, or equivalent AMD
128MB of Memory
AGP Graphics card with Direct Draw and 32MB of memory
DirectX 9.0 or later
Internet Explorer 5 or later
*
