Axis 0586-001 P33 1080P Fixed-Dome Network Security Camera

Overview

The 0586-001 2MP Dome Camera from AXIS Communications uses a 1/2.8" progressive-scan CMOS sensor for 1920 x 1080 resolution at 30 fps, and it features a 3-9mm varifocal lens for a 100° to 35° horizontal field of view. An integrated mechanical IR cut filter will automatically switch between color and B&W video, enabling clear images in various lighting conditions. Additionally, wide dynamic range offers high-quality images in ambient lighting, and color, brightness, sharpness, contrast, backlight compensation, and white balance settings allow you to configure your camera based on various environments. A mic/line input and line output provide 2-way audio capability, and a terminal block offers an alarm input and output for adding an external alarm to your surveillance system. Furthermore, ONVIF-compliance allows compatibility with additional surveillance items so that you can connect the camera to an NVR. The camera also comes with built-in analytics, such as motion detection, active tampering alarms, audio detection, autotracking, and line crossing. When any of these events occur, the camera will send you an email notification or store video recordings of the event to your edge storage. The camera compresses footage using H.264 and MJPEG formatting, maximizing your bandwidth and storage. Additionally, video can be streamed in multiple individual streams, and frame rates and bandwidth are controllable for further customizing your network. A microSD slot supports on-site recording, however, the camera can also record remotely to a dedicated NAS. The network is secured with a number of safety features, including password protection, IP address filtering, and HTTPs encryption. PoE technology allows you to transfer both data and power over the same Ethernet cable, minimizing the amount of cables needed during installation, and the camera's housing is IK10-rated impact resistant for use in high-risk settings.



Specifications

Model Number:  0586-001

Brand:  Axis Communications

Alt Part Number(s):  0586-001

Product Type:  Network Security Camera



Technical Description

Brand:  Axis Communications

Model:  0586-001

Product Name:  Axis 0586-001 Network Camera

Product Series:  P33

Product Type:  Network Camera

Network (RJ-45):  Yes

Color Supported:  Color

Connectivity Technology:  Cable

Maximum Video Resolution:  1920 x 1080

Form Factor:  Dome

Ethernet Technology:  Ethernet

Maximum Frame Rate:  60 fps

Ethernet:  Yes

Wide Angle:  Yes

Focus Modes:  Remote Focus

Application / Usage:  Indoor



Features

1920 x 1080 resolution at 30 fps for high quality video in real time

3-9mm varifocal lens for 100° to 35° horizontal FOV

IR cut filter automatically switched from color to B&W for clear details in low light

360° panning, 160° tilting, and 340° rotating during installation for angle adjustments

Multiple, individually configurable streams in H.264 and MJPEG

Controllable frame rate and bandwidth (VBR/MBR H.264)

Wide dynamic range allows you to take clear images in ambient lighting

Multiple image settings such as exposure control, exposure zones, rotation, and text and image overlay

Image enhancements include color, brightness, sharpness, white balance, and backlight compensation

Up to 2 individually cropped out view areas for multi-view streaming

Microphone/line input and line output for 2-way audio

Motion detection, active tampering, audio detection, line crossing, and autotracking alarms

All analytics, edge storage events, and external input detection will trigger an event alarm

When an alarm is triggered the camera will send you an email notification or save a video recording to edge storage

Network security features such as password protection, IP address filtering, and HTTPs encryption

PoE technology allows you to use one wire for both data and power

microSD slot supports microSD cards for edge storage

One alarm input and one alarm output for connecting an external alarm to the system

Vandal Resistant

Electronic Image Stabilization

Dust Resistant
