Description
Specifications
Model Number: 100-435843
Brand: ATI Technologies
Alt Part Number(s): X1950XTX / 109-A52031-50
Product Type: Video Graphic Adapter
Technical Description
Brand: ATI Technologies
Model: 100-435843 / X1950XTX / 109-A52031-50
Interface: PCI Express x16
Chipset Manufacturer: ATI
GPU: Radeon X1950XTX
Core Clock: 650 MHz
PixelPipelines: 16 (48 Pixel shader processor)
Effective Memory Clock: 2000MHz
Memory Size: 512MB
Memory Interface: 256-Bit
Memory Type: GDDR4
DirectX: DirectX 9
OpenGL: OpenGL 2.0
DVI Ports: 2 x DVI
TV-Out: HDTV / S-Video / Composite Out
VIVO: Yes
Tuner: None
RAMDAC: 400MHz
Max Resolution: 2560 x 1600
CrossFireX Support: Yes
Cooler: With Fan
Operating Systems Supported: Windows XP/XP x64/MCE 2005
Dual-Link DVI Supported: Yes
Windows Vista: Certified for Windows Vista
HDCP Ready: Yes
System Requirements
PCI Express based PC is required with one x16 lane graphics slot available on the motherboard and one additional adjacent expansion slot.
Connection to the system power supply is required:
450-Watt power supply or greater, 30 Amps on 12 volt rail recommended (assumes fully loaded system)
For CrossFire: 550 watt power supply or greater, 38 Amps on 12 volt rail
512MB of system memory
Installation software requires CD-ROM drive
DVD playback requires DVD drive and decoder software (not included)
Features
Shader Model 3.0
CrossFire ready
