AIC SB202-SP XP1-S202SP05 2U Intel Xeon 56 Core 256GB Barebone Server
SPECIAL ORDER ITEM
This product is available for special order and may take longer to ship.
AVAILABILITY & SHIPPING
We source this item directly from the OEM as a special order, which may result in longer lead times. We’ll keep you updated throughout the process.
NEED IT SOONER?
Contact us to explore expedited options or find a comparable in-stock alternative.
SPECIAL ORDER FULFILLMENT
Saitech Inc. sources special orders directly from manufacturers and authorized distributors, including hard-to-find, end-of-life, and build-to-order products. These items may have longer lead times, and our team will keep you informed throughout the process.
- Overview
The XP1-S202SP05 is a 2U rackmount server barebone system manufactured by AIC (Advanced Industrial Computer). It is designed for high-density storage and high-performance computing
Specifications
Model Number: XP1-S202SP05
Brand: AIC
Alt Part Number(s): XP1-S202SP05
Product Type: Barebone Server
Technical Description
Brand: AIC
Model Number: XP1-S202SP05
Series: SB202-SP
Processor Type: Intel Xeon Scalable
Processor Core: 56 Core/112 Thread
Processor Power: Up to 105W per CPU
Processor Socket: Dual Socket P0 (LGA 3647)
Motherboard: AIC Server Board Spica
Chipset Type: Intel C620
Graphics Controller: Integrated Aspeed AST2500
Ports: 2x USB 3.0 Type A Ports (rear), 1x VGA Port, 1x Serial Port, 2x RJ45 LAN Ports, 2x 10GbE SFP+ Ports (Optional BTO), 1x GbE RJ45 dedicated to BMC management Port
Networking: Integrated Intel I350 dual-port GbE LAN
RAID Levels: 0, 1, 5, 10
Number of Drive Bays: 12x 3.5" Hot-swap drive bays, 2x 2.5" Hot-swap rear drive bays for OS
Expansion Slots: 2×PCIe 3.0 x16, 5×PCIe 3.0 x8 (low profile)
Memory Supported: 3TB
Memory Size: 256GB
Memory Technology: DDR4 ECC Registered
Memory Speed: Up to 2933MHz
Memory Slots: 12 (6 slots per CPU)
Power Supply: 800W 80+ Platinum Redundant
System Cooling: 3x 80x38mm System Fans
Form Factor: 2U Rackmount
