- Overview
The XP1-S203LX01 is a 2U 8-bay storage server barebone system from Advanced Industrial Computer (AIC), specifically part of the SB203-LX series. It is designed for high-density storage and general-purpose GPU applications.
Specifications
Model Number: XP1-S203LX01
Brand: AIC
Alt Part Number(s): XP1-S203LX01
Product Type: Barebone Server
Technical Description
Brand: AIC
Model Number: XP1-S203LX01
Series: SB203-LX
Processor Type: Intel Xeon Scalable
Processor Core: 56 Core/112 Thread
Processor Power: TDP up to 205W
Processor Socket: LGA 1151 (Socket H4)
Chipset Type: Intel Lewisburg C620 series PCH
Motherboard: AIC Lynx Server Board
Graphics Controller: Aspeed AST2500
Ports: 2x USB 3.0 Type A (Front), 1x VGA, 1x Serial (Rear) , 1x RJ45 dedicated for BMC management Port
Networking: 2x Gigabit Ethernet (GbE) RJ45 Ports
Number of Drive Bays: 8x 3.5" hot-swap SAS/SATA bays(External), 2x 2.5" Internal OS kit,
2x M.2 (NGFF) slots (M-Key, 2280) supporting SATA or PCIe x2
Expansion Slots: Up to 6 × PCIe Gen3 x16 Slots
Memory Supported: Up to 3TB using 3DS ECC RDIMM or LRDIMM
Memory Size: 128GB each DIMM
Memory Technology: DDR4
Memory Speed: 2933 / 2666 / 2400 MHz
Memory Slots: 24 DIMM slots
Channels: 6 Channels per CPU
Power Supply: 800W 1+1 redundant 80+ Platinum
System Cooling: 5x 6056 easy-swap fans
Form Factor: 2U Rackmount
Height: 3.5"
Width: 17.2"
Depth: 31.5"
