Aten CC2000-SD Standard 1-Master 1-Slave up to 512-Nodes Network Management Software

Overview

ATEN's CC2000 ?áManagement Software?áprovides IT administrators with the tools they need to access and control their entire distributed data center environment. It has been updated over the previous version and delivers new features such as VMware support. Offering convenient, economical, and centralized management of all IT devices, it puts administrators in complete control of their remote data centers and branch offices no matter where in the world they are deployed. When used in conjunction with KVM over IP switches, Serial Console Servers, and Power Over the NET devices, the CC2000 management software allows IT administrators to remotely monitor and control all installed devices like blade servers and virtual machines. The CC2000's Primary-Secondary architecture safeguards data transmissions through built-in redundancy factors including automated database backup of Primary servers, Secondary servers, and devices, as well as real-time database updating. Redundancy ensures that should any of the CC2000 servers go down, the CC2000 management system will keep functioning since a redundant Secondary unit provides the required services until the Primary unit comes back up. With the double redundancy feature, each Secondary server can have its own redundant Secondary server, which ensures smooth management of all your devices

?áPowerful Security

Powerful security features include both internal and external authentication - external authentication support includes LDAP, LDAPS, Kerberos, Active Directory, RADIUS, TACACS+, and NT Domain Option to force users of all CC-managed devices to be authenticated through the CC - users cannot log in to the devices directly Compliant with the x.509 Digital Certificate Standard Supports SSL 128-bit data encryption and RSA 1024-bit certificates to secure users log in from the browser Flexible session time-outs Configurable user and group permissions for server access and control Supports strong password protection, SAS 70 compliance for a configurable amount of failed login attempts and user ID lock out parameters Devices can identify themselves by Name, MAC address or IP in the browser

Specifications

Model Number:?á CC2000-SD

Brand:?á Aten

Alt Part Number(s):?á CC2000-SD

Product Type:?á Management Software

?á

Technical Description

Brand:?á?á Aten

Model:?á?áCC2000-SD

?á

Service processor:?á

Dell iDRAC5/6/8,

HP iLO2/3/5, Redfish,

IBM RSA II, Dell CMC,

?áIBM AMM, HP OA, IPMI, IMM.

Network Protocol & IP Tools:?á

IPv4/IPv6, RDP, VNC,

SSH, and Telnet.

Logs:?á

System logs.

Device logs. Serial

console server logs.

SNMP traps. Activity report.

Viewer

Java Client (JNLP).

Win Client (ActiveX).

Mouse DynaSync.

Panel array mode (up to 64 KVM ports).

Virtual media.

Notification SMTP.

SNMP (v1, v2c, v3). Syslog.

System message.

Task scheduling

CC2000 database backup.

CC2000 configuration backup.

Device firmware upgrade.

Export system logs.

Export device logs.

Export serial console server logs.

Power on/off control on ATEN PDU.

Security

AES 256-bit encryption for secure end-to-end node access.

IP or MAC addresses blocking.

Virtual media security blocking.

Configurable failed login attempts and lockout.

Support certificate signed by third-party authorities (CA).

Secure web connection with TLS v1.2 and RSA 2048-bit certificates.

Strong user password authentication.

Configurable user session timeout.

Features:

Access control to grant or restrict user access by IP or MAC address, and SAS 70 compliance for configurable failed login attempts and lockout Supports certificates signed from third-party authorities (CA) TLS v1.2 data encryption and RSA 2048-bit certificates to secure user logins from browser strong user password policy to enhance the security of user accounts

Consolidates logs from ATEN?ÇÖs KVM over IP switches, serial console servers, and other devices through syslog protocol for audit trail

Message Box ?Çö shows internal system messages or critical logs that can be viewed in full detail with just one simple click.

Panel Array Mode ?Çô allows administrators to monitor multiple video outputs of remote servers in one screen Mouse DynaSync ?Çô automatically synchronizes the local and remote mouse cursors

Delivers server redundancy through primary/secondary architecture for service availability Add specific devices and ports to My Favorites for quick access

*Product descriptions, images, and part numbers are subject to change and may not accurately reflect manufacturer product alterations. For the latest and most precise information, kindly refer to the manufacturer's website and use the item's manufacturer part number.
